Thermal spraying

Surface finishes for the present and future

Thermal spraying technology allows creation and application of metal, metal-ceramic and ceramic coatings on all types of metal construction materials - regardless of the condition of the thermal treatment. Neither chemical composition of the base material of the coated panels, nor the condition of the thermal treatment are essential for the application of thermal spraying. The coatings can be applied only to parts with already existing layers – for example nitriding or chromium-plating.

Žárové stříkání

The aim of applying coatings technologies created by thermal spraying is to modify or renovate functional surfaces with specific properties on machinery parts - while reducing manufacturing and operating costs. The technology can be used in primary production, repairing and renovation.

Spray processes:
Classification according to energy carrier
Process abbreviations
TS by atomising a melt Molten-bath spraying MBS
TS by means of gaseous or liquid fuels Wire flame spraying WFS
Hight velocity wire flame spraying HVWFS
Powder flame spraying PFS
Hight velocity flame spraying HVOF
Detonation spraying DGS
TS by means of expansion of highly pressurised gases without combustion Cold spraying CGS
TS by means of electric arc or gas discharge Arc spraying AS
Shrouded arc spraying SAS
Plazma spraying in air APS
Shrouded plasma spraying SPS
Plazma spraying in chumber under vacuum VPS
Plazma spraying in chumber at pressures exceeding 1 bar HPPS
Liquid stabilised plasma spraying LSPS
Inductively coupled plasma spraying ICPS
TS by means of bundled light stream Laser spraying LS

How are the coatings with unique properties created?

Jak vznikají povlaky unikátních vlastností

During the coating process, the base material is heated to approx. 100 °C, in exceptional cases up to 150 °C. Consequently, there is no deformation of the coated panel, nor degradation of the base material structure. Generally, the coating process using thermal spraying technologies can be described as melting of the accessory material in the form of powder, wire or rod. Its particles are accelerated and deposited on a prepared, blasted surface of the components. After the impact on the base material, individual particles are partially or completely deformed and cooled, hardened and forming typical structure of the coating very quickly.

Coating thickness ranges from 0.1 mm to several millimeters depending on the method. THERMALMETAL owns device for all four basic methods of thermal spraying: flame, electric arc, plasma and high-velocity oxy-fuel coating. Our shop is equipped with robotized systems ensuring high reliability and reproducibility of the coating process on different material shapes - rotary, flat and other complex shapes – and, with certain limitations, even in holes.

We are able to fully assess your specific requirements and, in cooperation with your engineers and technologists, design optimal technological processes. If you need to coat large parts, we can do the job at your site. Do not hesitate to contact us about the specifics.

Basic methods

Flame spraying

Žárové stříkání plamenem

This method is no longer being developed and is used only in very specific applications. In comparison with other thermal spraying methods, these coatings have the weakest of basic characteristics (adhesion, cohesion, etc.), and a highly porous layer. In metal coatings, there is a high percentage of oxides, which on one hand increases the hardness, but reduces durability, cohesion of the coating and its adhesion on the other. In thermal spraying by flame, it is possible to use accessory additional material in the form of powder, wire or rod.

Electric arc spraying

Žárové stříkaní elektrickým obloukem

Arc spraying is especially suitable for renovations and repairs. Particularly where the wear is higher - typically for forming a layer of a thickness of 1-4 mm. It is often used as priming for ceramic and metal-ceramic coatings, requiring creation of a priming coat with higher strength and toughness than the base material.

Plasma-spraying

Žárové stříkaní plazmou

It is the most versatile method suitable for spraying of coatings with high quality and often unique properties. Plasma spraying is preferred for the formation of homogeneous and functionally graded, protective and functional coatings of metal and ceramic materials or metal-ceramic mixture. If necessary, it is possible to modify or even entirely eliminate porosity of the coating.

High-velocity oxy-fuel coating

Žárové stříkaní vysokorychlostní stříkání plamenem

Coating carried out at high speeds that reach up to several hundred meters per second. The result are coatings with high adhesion and coherence of particles.

The above methods can produce high quality metal, metal-ceramic, ceramic and remelted coatings.
